Troubleshooting CyberPower PowerPanel issues in Linux
Table of Contents
I have a CyberPower BRG1350AVRLCD at home and I’ve just connected it to a new device. However, the pwrstat command doesn’t retrieve any useful data on the new system:
# pwrstat -status
The UPS information shows as following:
Current UPS status:
State........................ Normal
Power Supply by.............. Utility Power
Last Power Event............. None
I disconnected the USB cable and ran pwrstat again. Same output. I disconnected power from the UPS itself and ran pwrstat again. Same output. This can’t be right.
Checking the basics #
A quick look at dmesg output shows that the UPS is connected and the kernel recognizes it:
[ 65.661489] usb 3-1: new full-speed USB device number 7 using xhci_hcd
[ 65.830769] usb 3-1: New USB device found, idVendor=0764, idProduct=0501
[ 65.830771] usb 3-1: New USB device strings: Mfr=3, Product=1, SerialNumber=2
[ 65.830772] usb 3-1: Product: BRG1350AVRLCD
[ 65.830773] usb 3-1: Manufacturer: CPS
[ 65.830773] usb 3-1: SerialNumber: xxxxxxxxx
[ 65.837801] hid-generic 0003:0764:0501.0004: hiddev0,hidraw0: USB HID v1.10 Device [CPS BRG1350AVRLCD] on usb-0000:00:14.0-1/input0
I checked the /var/log/pwrstatd.log file to see if there were any errors:
2017/07/25 12:01:17 PM Daemon startups.
2017/07/25 12:01:24 PM Communication is established.
2017/07/25 12:01:27 PM Low Battery capacity is restored.
2017/07/25 12:05:19 PM Daemon stops its service.
2017/07/25 12:05:19 PM Daemon startups.
2017/07/25 12:05:19 PM Communication is established.
2017/07/25 12:05:22 PM Low Battery capacity is restored.
2017/07/25 12:06:27 PM Daemon stops its service.
The pwrstatd daemon can see the device and communicate with it. This is unusual.
Digging into the daemon #
If the daemon can truly see the UPS, then what is it talking to? I used lsof to examine what the pwrstatd daemon is doing:
# lsof -p 3975
COMMAND PID USER FD TYPE DEVICE SIZE/OFF NODE NAME
pwrstatd 3975 root cwd DIR 8,68 224 96 /
pwrstatd 3975 root rtd DIR 8,68 224 96 /
pwrstatd 3975 root txt REG 8,68 224175 134439879 /usr/sbin/pwrstatd
pwrstatd 3975 root mem REG 8,68 2163104 134218946 /usr/lib64/libc-2.25.so
pwrstatd 3975 root mem REG 8,68 1226368 134218952 /usr/lib64/libm-2.25.so
pwrstatd 3975 root mem REG 8,68 19496 134218950 /usr/lib64/libdl-2.25.so
pwrstatd 3975 root mem REG 8,68 187552 134218939 /usr/lib64/ld-2.25.so
pwrstatd 3975 root 0r CHR 1,3 0t0 1028 /dev/null
pwrstatd 3975 root 1u unix 0xffff9e395e137400 0t0 37320 type=STREAM
pwrstatd 3975 root 2u unix 0xffff9e395e137400 0t0 37320 type=STREAM
pwrstatd 3975 root 3u unix 0xffff9e392f0c0c00 0t0 39485 /var/pwrstatd.ipc type=STREAM
pwrstatd 3975 root 4u CHR 180,96 0t0 50282 /dev/ttyS1
Wait a minute. The last line of the lsof output shows that pwrstatd is talking to /dev/ttyS1, but the device is supposed to be a hiddev device over USB. If you remember, we had this line in dmesg when the UPS was plugged in:
hid-generic 0003:0764:0501.0004: hiddev0,hidraw0: USB HID v1.10 Device [CPS BRG1350AVRLCD] on usb-0000:00:14.0-1/input0
Things are beginning to make more sense now. I have a USB-to-serial device that allows my server to talk to the console port on my Cisco switch:
[ 80.389533] usb 3-1: new full-speed USB device number 9 using xhci_hcd
[ 80.558025] usb 3-1: New USB device found, idVendor=067b, idProduct=2303
[ 80.558027] usb 3-1: New USB device strings: Mfr=1, Product=2, SerialNumber=0
[ 80.558028] usb 3-1: Product: USB-Serial Controller D
[ 80.558029] usb 3-1: Manufacturer: Prolific Technology Inc.
[ 80.558308] pl2303 3-1:1.0: pl2303 converter detected
[ 80.559937] usb 3-1: pl2303 converter now attached to ttyUSB0
It appears that pwrstatd is trying to talk to my Cisco switch (through the USB-to-serial adapter) rather than my UPS! I’m sure they could have a great conversation together, but it’s hardly productive.
Fixing it #
The /etc/pwrstatd.conf has a relevant section:
# The pwrstatd accepts four types of device node which includes the 'ttyS',
# 'ttyUSB', 'hiddev', and 'libusb' for communication with UPS. The pwrstatd
# defaults to enumerate all acceptable device nodes and pick up to use an
# available device node automatically. But this may cause a disturbance to the
# device node which is occupied by other software. Therefore, you can restrict
# this enumerate behave by using allowed-device-nodes option. You can assign
# the single device node path or multiple device node paths divided by a
# semicolon at this option. All groups of 'ttyS', 'ttyUSB', 'hiddev', or
# 'libusb' device node are enumerated without a suffix number assignment.
# Note, the 'libusb' does not support suffix number only.
#
# For example: restrict to use ttyS1, ttyS2 and hiddev1 device nodes at /dev
# path only.
# allowed-device-nodes = /dev/ttyS1;/dev/ttyS2;/dev/hiddev1
#
# For example: restrict to use ttyS and ttyUSB two groups of device node at
# /dev,/dev/usb, and /dev/usb/hid paths(includes ttyS0 to ttySN and ttyUSB0 to
# ttyUSBN, N is number).
# allowed-device-nodes = ttyS;ttyUSB
#
# For example: restrict to use hiddev group of device node at /dev,/dev/usb,
# and /dev/usb/hid paths(includes hiddev0 to hiddevN, N is number).
# allowed-device-nodes = hiddev
#
# For example: restrict to use libusb device.
# allowed-device-nodes = libusb
allowed-device-nodes =
We need to explicitly tell pwrstatd to talk to the UPS on /dev/hid/hiddev0:
allowed-device-nodes = /dev/usb/hiddev0
Let’s restart the pwrstatd daemon and see what we get:
# systemctl restart pwrstatd
# pwrstat -status
The UPS information shows as following:
Properties:
Model Name................... BRG1350AVRLCD
Firmware Number..............
Rating Voltage............... 120 V
Rating Power................. 810 Watt(1350 VA)
Current UPS status:
State........................ Normal
Power Supply by.............. Utility Power
Utility Voltage.............. 121 V
Output Voltage............... 121 V
Battery Capacity............. 100 %
Remaining Runtime............ 133 min.
Load......................... 72 Watt(9 %)
Line Interaction............. None
Test Result.................. Unknown
Last Power Event............. None
Success!
