Fixing OpenStack noVNC consoles that ignore keyboard input

··561 words·3 mins·
Kvm Network Openstack Python Vnc
Table of Contents

I opened up a noVNC console to a virtual machine today in my OpenStack cloud but found that the console wouldn’t take keyboard input. The Send Ctrl-Alt-Del button in the top right of the window worked just fine, but I couldn’t type anywhere in the console. This happened on an Ocata OpenStack cloud deployed with OpenStack-Ansible on CentOS 7.

Test the network path #

The network path to the console is a little deep for this deployment, but here’s a quick explanation:

  • My laptop connects to HAProxy
  • HAProxy sends the traffic to the nova-novncproxy service
  • nova-novncproxy connects to the correct VNC port on the right hypervisor

If all of that works, I get a working console! I knew the network path was set up correctly because I could see the console in my browser.

My next troubleshooting step was to dump network traffic with tcpdump on the hypervisor itself. I dumped the traffic on port 5900 (which was the VNC port for this particular instance) and watched the output. Whenever I wiggled the mouse over the noVNC console in my browser, I saw a flurry of network traffic. The same thing happened if I punched lots of keys on the keyboard. At this point, it was clear that the keyboard input was making it to the hypervisor, but it wasn’t being handled correctly.

Test the console #

Next, I opened up virt-manager, connected to the hypervisor, and opened a connection to the instance. The keyboard input worked fine there. I opened up remmina and connected via plain old VNC. The keyboard input worked fine there, too!

Investigate in the virtual machine #

The system journal in the virtual machine had some interesting output:

kernel: atkbd serio0: Unknown key released (translated set 2, code 0x0 on isa0060/serio0).
kernel: atkbd serio0: Use 'setkeycodes 00 <keycode>' to make it known.
kernel: atkbd serio0: Unknown key released (translated set 2, code 0x0 on isa0060/serio0).
kernel: atkbd serio0: Use 'setkeycodes 00 <keycode>' to make it known.
kernel: atkbd serio0: Unknown key pressed (translated set 2, code 0x0 on isa0060/serio0).
kernel: atkbd serio0: Use 'setkeycodes 00 <keycode>' to make it known.
kernel: atkbd serio0: Unknown key pressed (translated set 2, code 0x0 on isa0060/serio0).
kernel: atkbd serio0: Use 'setkeycodes 00 <keycode>' to make it known.
kernel: atkbd serio0: Unknown key released (translated set 2, code 0x0 on isa0060/serio0).
kernel: atkbd serio0: Use 'setkeycodes 00 <keycode>' to make it known.
kernel: atkbd serio0: Unknown key released (translated set 2, code 0x0 on isa0060/serio0).
kernel: atkbd serio0: Use 'setkeycodes 00 <keycode>' to make it known.

It seems like my keyboard input was being lost in translation - literally. I have a US layout keyboard (Thinkpad X1 Carbon) and the virtual machine was configured with the en-us keymap:

# virsh dumpxml 4 | grep vnc
    <graphics type='vnc' port='5900' autoport='yes' listen='192.168.250.41' keymap='en-us'>

A thorough Googling session revealed that it is not recommended to set a keymap for virtual machines in libvirt in most situations. I set the nova_console_keymap variable in /etc/openstack_deploy/user_variables.yml to an empty string:

nova_console_keymap: ''

I redeployed the nova service using the OpenStack-Ansible playbooks:

openstack-ansible os-nova-install.yml

Once that was done, I powered off the virtual machine and powered it back on. (This is needed to ensure that the libvirt changes go into effect for the virtual machine.)

Great success! The keyboard was working in the noVNC console once again!
