Deploy a custom Fedora 35 AMI to AWS with Image Builder

Table of Contents

Fedora reigns supreme as my Linux distribution of choice when I deploy new workloads to public clouds. It gives me a well-tested, modern Linux system with tons of helpful tools.

Fedora’s cloud images provide a great base to begin building a cloud deployment, but sometimes I find myself wanting a highly customized image with some features I care about. For example, I may want some packages pre-installed that aren’t included with the default cloud image, or I may want certain services stopped or started at boot time.

Fortunately, Fedora includes Image Builder. Image Builder does the hard work of building your image, uploading it to a cloud provider, and then registering that image. It has built-in support for handing AMIs (Amazon Machine Images) at AWS and you can use it as a one-stop-shop for customizing an AMI for your use case.

Configure the AWS cli #

Start by installing the awscli package:

$ sudo dnf install awscli

The cli will need some way to access your AWS account. I usually create an administrative user and attach an administrative policy to the user. This allows me to control my entire account via the cli tool.

💣 (Note: Although this works well for my simple uses here, be careful using administrative users on large accounts. You may want to be more restrictive with your IAM policies, but that’s a topic for a different post.)

We start by accessing the IAM dashboard in your AWS account. Follow these steps:

Click Users on the left and then Add users on the right
Enter a name for your user (I used desktop-cli)
Click the Access key - Programmatic access checkbox
Click Next: Permissions
Click Attach existing policies directly and then tick the box next to Administrator Access
Click Next: Tags and add any tags if your organization requires them
Click Next: Review and then Create User

The next screen shows your Access key ID and your Secret access key. Click Show to display your secret access key. Go back to your cli tool and run the configuration command:

$ aws configure --profile personal
AWS Access Key ID [None]: << enter your access key id here >>
AWS Secret Access Key [None]:<< enter your secret access key here >>
Default region name [None]: us-east-1
Default output format [None]:

Let’s verify that the credentials work:

$ aws --profile personal sts get-caller-identity
{
    "UserId": "xxx",
    "Account": "xxx",
    "Arn": "arn:aws:iam::xxx:user/desktop-cli"
}

To avoid typing your profile over and over, just export an environment variable:

$ export AWS_PROFILE=personal

Preparing permissions for image imports #

When you import images into AWS, some services must take action on your behalf to copy your image from S3 into an EBS snapshot, and then register that snapshot as an AMI. This requires an S3 bucket and some extra permissions for some AWS services.

First off, let’s create an S3 bucket to hold our image:

$ aws s3 mb s3://image-upload-bucket-blog-post
make_bucket: image-upload-bucket-blog-post

From here, we follow the AWS documentation for importing images with some slight modifications for Image Builder. Save this file as trust-policy.json:

{
   "Version": "2012-10-17",
   "Statement": [
      {
         "Effect": "Allow",
         "Principal": { "Service": "vmie.amazonaws.com" },
         "Action": "sts:AssumeRole",
         "Condition": {
            "StringEquals":{
               "sts:Externalid": "vmimport"
            }
         }
      }
   ]
}

Now we create the vmimport role with the policy that allows AWS to assume this role and import an image:

$ aws iam create-role --role-name vmimport \
    --assume-role-policy-document "file://trust-policy.json"

We need to set some policy for our new vmimport role now to limit what AWS is allowed to do in our account. Save the following as role-policy.json:

{
   "Version":"2012-10-17",
   "Statement":[
      {
         "Effect": "Allow",
         "Action": [
            "s3:GetBucketLocation",
            "s3:GetObject",
            "s3:ListBucket"
         ],
         "Resource": [
            "arn:aws:s3:::image-upload-bucket-blog-post",
            "arn:aws:s3:::image-upload-bucket-blog-post/*"
         ]
      },
      {
         "Effect": "Allow",
         "Action": [
            "ec2:ModifySnapshotAttribute",
            "ec2:CopySnapshot",
            "ec2:RegisterImage",
            "ec2:Describe*"
         ],
         "Resource": "*"
      }
   ]
}

🛑 Stop here and change image-upload-bucket-blog-post to the S3 bucket name that you used in the first step of this section.

$ aws iam put-role-policy --role-name vmimport --policy-name vmimport \
    --policy-document "file://role-policy.json"

Image Builder also needs a user that can perform some functions inside AWS to upload and import the image. Let’s create a policy for a new user and save it as image-builder-policy.json:

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Sid": "VisualEditor0",
            "Effect": "Allow",
            "Action": [
                "ec2:CreateTags",
                "ec2:RegisterImage",
                "ec2:ImportSnapshot",
                "ec2:DescribeImportSnapshotTasks"
            ],
            "Resource": "*"
        },
        {
            "Sid": "VisualEditor1",
            "Effect": "Allow",
            "Action": [
                "s3:PutObject",
                "s3:GetObject",
                "s3:DeleteObject"
            ],
            "Resource": "arn:aws:s3:::image-upload-bucket-blog-post/*"
        }
    ]
}

Add the policy, create a user, and attach the policy to your user:

$ aws iam create-policy --policy-name imagebuilder \
    --policy-document "file://image-builder-policy.json"
$ aws iam create-user --user-name imagebuilder
$ aws iam attach-user-policy --user-name imagebuilder \
    --policy-arn arn:aws:iam::YOUR_ACCOUNT_NUMBER:policy/imagebuilder

The ARN for your IAM policy includes your account number and the ARN should appear after running the create-policy command.

Install Image Builder #

It’s no secret that I love good command line tools over graphical interfaces, so we will follow the cli steps for Image Builder in the remainder of this post. Let’s start by installing everything we need for Image Builder and starting the socket activation unit:

$ sudo dnf install composer-cli osbuild-composer
$ sudo systemctl enable --now osbuild-composer.socket

Verify that osbuild-composer is listening:

$ composer-cli status show
API server status:
    Database version:   0
    Database supported: true
    Schema version:     0
    API version:        1
    Backend:            osbuild-composer
    Build:              NEVRA:osbuild-composer-%{epoch}:37-1.fc35.x86_64

That was easy!

Build and deploy our AMI #

Image Builder uses specifications called blueprints. These are TOML files that tell Image Builder how to configure your image. You can configure these in many different ways, but here’s the one I’m using for this post:

name = "major-perfect-f35"
description = "Major's perfect Fedora 35 cloud image"
version = "0.0.1"

[[packages]]
name = "firewalld"

[[packages]]
name = "tmux"

[[packages]]
name = "vim"

[[packages]]
name = "zsh"

[[customizations.user]]
name = "major"
key = "ecdsa-sha2-nistp256 AAAAE2VjZHNhLXNoYTItbmlzdHAyNTYAAAAIbmlzdHAyNTYAAABBBIcfW3YMH2Z6NpRnmy+hPnYVkOcxNWLdn9VmrIEq3H0Ei0qWA8RL6Bw6kBfuxW+UGYn1rrDBjz2BoOunWPP0VRM= major@amdbox"
shell = "/usr/bin/zsh"
groups = ["wheel"]

[customizations.timezone]
timezone = "America/Chicago"

[customizations.firewall.services]
enabled = ["ssh", "dhcpv6-client"]

[customizations.services]
enabled = ["sshd", "firewalld"]

I saved this file as image.toml. The next step involves pushing the blueprint and solving the dependencies in the blueprint:

$ composer-cli blueprints push image.toml
$ composer-cli blueprints depsolve major-perfect-f35

We need some extra configuration to tell Image Builder how to authenticate with AWS. Save this file as aws.toml:

provider = "aws"

[settings]
accessKeyID = "YOUR_ACCESS_KEY_ID"
secretAccessKey = "YOUR_SECRET_ACCESS_KEY"
bucket = "image-upload-bucket-blog-post"
region = "us-east-1"
key = "major-perfect-f35"

Replace the bucket name with your S3 bucket and set an S3 object name in key. To get your access key and secret access key, run this command:

$ aws iam create-access-key --user imagebuilder

Finally, we’re ready to tell Image Builder to deploy our image! Run this last command to start the compose:

composer-cli compose start major-perfect-f35 ami major-perfect-f35 aws.toml

Replace major-perfect-35 with the name in your blueprint. Now, follow along in the system journal as your image is deployed:

[AWS] 🚀 Uploading image to S3: image-upload-bucket-blog-post/major-perfect-f35
[AWS] 📥 Importing snapshot from image: image-upload-bucket-blog-post/major-perfect-f35
[AWS] 🚚 Waiting for snapshot to finish importing: import-snap-06bc48cb9779f98d8
[AWS] 🧹 Deleting image from S3: image-upload-bucket-blog-post/major-perfect-f35
[AWS] 📋 Registering AMI from imported snapshot: snap-02ed2710572b7b94b
[AWS] 🎉 AMI registered: ami-0964ea222b6a6711e

(Don’t ask me who put all of the emojis in the logging code. 🤭)

Let’s verify that our image is fully imported:

$ aws ec2 describe-images --filters "Name=tag:Name,Values=major-perfect-f35"
{
    "Images": [
        {
            "Architecture": "x86_64",
            "CreationDate": "2021-11-16T18:12:33.000Z",
            "ImageId": "ami-0964ea222b6a6711e",
            "ImageLocation": "xxx/major-perfect-f35",
            "ImageType": "machine",
            "Public": false,
            "OwnerId": "xxx",
            "PlatformDetails": "Linux/UNIX",
            "UsageOperation": "RunInstances",
            "State": "available",
            "BlockDeviceMappings": [
                {
                    "DeviceName": "/dev/sda1",
                    "Ebs": {
                        "DeleteOnTermination": true,
                        "SnapshotId": "snap-02ed2710572b7b94b",
                        "VolumeSize": 6,
                        "VolumeType": "gp2",
                        "Encrypted": false
                    }
                }
            ],
            "EnaSupport": true,
            "Hypervisor": "xen",
            "Name": "major-perfect-f35",
            "RootDeviceName": "/dev/sda1",
            "RootDeviceType": "ebs",
            "Tags": [
                {
                    "Key": "Name",
                    "Value": "major-perfect-f35"
                }
            ],
            "VirtualizationType": "hvm"
        }
    ]
}

Go forth and build instances with your new, customized Fedora 35 AMI! 🎉
